Four-point Contact Ball Bearing

Series

Click series for Specification Chart

Series

Range

Four-point Contact Ball Bearing

Schematic Diagram:

Parameters:

The contact angle of the Four-point Contact Ball Bearing is usually 35°. When carrying pure radial loads, each ball contacts with rings at four-point, and they are two-point contact under purely axial loads. The bearings can carry axial loads in two directions and specific moment loads. This type of bearings typically works at high speed when two-point contact is formed.

Dimensions				Basic load ratings		Designations		Mass	Installation dimersion			Limiting speeds
mm				kN		Current	Original	kg	mm			r/min
d	D	B	rmin	Cr	Cor	Current	Original	kg	damin	Damax	ramax	Grease	Oil
120	180	28	2	148	196	QJ1024		2.65	130	170	2	2600	3600
	215	40	2.1	286	340	QJ224		6.95	132	203	2	2200	3200
	260	55	3	390	490	QJ324		16	148	292	3	1900	2800
130	200	33	3	182	240	QJ1026		4.05	140	190	2	2200	3200
	230	40	3	296	365	QJ226		7.75	144	216	2.5	1900	2800
	280	58	4	423	560	QJ326		19.5	148	262	3	1800	2600
140	210	22	1.1	121	163	605647A		2.6	147	203	1	2000	3000
	210	33	2	190	265	QJ1028		4.3	150	200	2	2000	3000
	250	42	3	325	440	QJ228		9.85	154	236	2	1800	2600
	300	62	4	468	640	QJ328		24	158	282	3	1700	2400
150	225	35	2.1	225	275	QJ1030	176130	5.1	162	213	2	1900	2800
	270	45	3	302	372	QJ230	176230	12.5	164	256	2.5	1700	2400
	320	65	4	494	710	QJ330	176330	29	168	302	2	1600	2200
160	240	38	2.1	260	318	QJ1032	176132	6.3	172	228	2	1800	2600
	290	48	3	352	455	QJ232	176232	14.6	174	276	2.5	1600	2200
	340	68	4	585	865	QJ332	176332	31	178	388	3	1500	2000
170	260	42	2.1	226	350	QJ1034	176134	8.5	182	248	2	1700	2400
	265	42	2.1	226	350	QJF1034X1	176734X1	9	182	248	2	1300	1600
	310	52	4	358	480	QJ234	176234	19.5	188	292	3	1600	2200
	360	72	4	618	965	QJ334	176334	41.5	188	342	3	1400	1900
180	280	46	2.1	335	408	QJ1036	176136	11	192	268	2	1600	2200
	320	52	4	392	545	QJ236	176236	20.5	198	3020	3	1500	2000
	380	75		637	1020	QJ336		47.5	198	362	3	1300	1800

Dimensions				Basic load ratings		Designations		Mass	Installation dimersion			Limiting speeds
mm				kN		Current	Original	kg	mm			r/min
d	D	B	rmin	Cr	Cor	Current	Original	kg	damin	Damax	ramax	Grease	Oil
190	290	46	2.1	348	430	QJ1038	179138	11.5	202	278	2	1600	2200
	340	55	4	455	735	QJ238	176238	39	208	322	3	1400	2200
200	310	51	2.1	380	498	QJ1040	176140	14.9	212	298	2	1500	2000
	360	58	4	507	850	QJ240	176240	27	218	342	3	1300	1800
	360	70	4	520	865	QJF1240	-	32.5	218	342	3	1300	1800
220	340	56	3	448	622	QJ1044	176144	19.6	234	326	2.5	1300	1800
	400	78	4	592	1020	QJ1244		45.5	238	382	3	1100	1600
	460	88	5	780	1400	QJ344		78	242	438	4	1000	1500
240	360	56	3	458	655	QJ1048	176148	21	254	346	2.5	1200	1700
	440	85	4	663	1220	QJ1248		61	258	422	3	1000	1500
260	360	46	2.1	390	710	QJ1952		15	271	349	2	1100	1600
	400	65	4	510	765	QJ1052	176152	31.3	278	382	3	1000	1500
280	420	65	4	540	835	QJ1056	176156	33.2	298	402	3	950	1400
	500	90	5	728	1460	QJ1256		82	302	478	4	950	1400
300	460	74	4	630	1040	QJF1060	116160	47	318	442	3	900	1300
	540	98	5	832	1760	QJ1260		105	322	518	4	850	1200
320	480	74	4	650	1090	QJ1064	176164	49.5	338	462	3	850	1200
	580	105	5	923	2040	QJ1264		130	342	558	4	800	1100
340	520	82	5	725	1270	QJ1068	176168	67.5	362	498	4	800	1100
	620	118	6	1060	2450	QJ1268		165	368	592	5	750	1000
360	540	82	5	768	1380	QJ1072	176172	69.2	382	518	4	800	1100
	650	122	6	999	2340	QJ 1272	1176272	190	388	622	5	700	950

Dimensions				Basic load ratings		Designations		Mass	Installation dimersion			Limiting speeds
mm				kN		Current	Original	kg	mm			r/min
d	D	B	rmin	Cr	Cor	Current	Original	kg	damin	Damax	ramax	Grease	Oil
380	560	82	5	737	1710	QJ1076	176176	73.5	402	538	4	750	1000
	680	132	6	1053	2565	QJ1276	1176276	220	408	652	5	670	900
400	600	90	5	814	1944	QJ1080	176180	95.5	422	578	4	700	950
	720	140	6	1170	2925	QJ1280	1176280	265	428	692	5	600	800
420	560	65	4	573	1440	QJ1984	1176984	51	438	542	3	700	950
	620	90	5	831	2052	QJ1084	176184	99.5	442	598	4	670	900
	760	150	7.5	1287	3375	QJ1284	1176284	315	456	724	6	560	750
440	600	74	4	685	1710	QJ1988	1176988	65	458	582	3	670	900
	650	94	6	896	2250	QJ1088	176188	115	468	622	5	630	850
	790	155	7.5	1260	3375	QJ1288	1176288	350	476	754	6	560	750
460	680	100	6	936	2385	QJ1092	176192	130	488	652	5	600	800
	830	165	7.5	1377	3825	QJ1292	1176292	415	496	794	6	530	700
480	700	100	6	954	2520	QJ1096	176196	135	508	672	5	560	750
	870	170	7.5	1512	4275	QJ1296	1176296	470	516	834	6	500	670
